Microwave Motion Sensor with High Accuracy and Sensitivity

accurate motion sensor for LED lights

ADM stocks the Hytronik HC005S microwave motion sensor.


Hytronik HC005S
Hytronik HC005S


The HC005S provides straight froward mains on /off switching control when motion is detected.

The key benefit of the HC005S is its high level of sensitivity and accuracy.

The sensitivity level can be adjusted for optimal control of the detection area.

For further flexibility, you can also select the preferred hold time as follows:

  • 5s
  • 30s
  • 1min
  • 5min
  • 10min
  • 20min
  • 30min

One HC005S can switch up to 400W of LED drivers.

Another advantage is the built-in zero cross switching control, which eliminates high inrush current at start up that can cause miniature circuit breakers (MCBs) to trip.

An inbuilt daylight sensor with adjustable lux setting allows you to save energy by determining how the sensor behaves in different lighting conditions. For example, you could use the sensor in one of the ways below:

  • Daylight operation: The LED always switches on, even during daylight hours.
  • Twilight operation: The LED switches on in twilight and darkness.
  • Darkness operation: The LED only switches on when it is dark.

For convenient installation extra connection points are provided for the looping of input and output AC cables.

The Hytronik HC005S comes with a 5-year manufacturer's warranty.

Please do not hesitate to contact ADM if you would like assistance with selecting a suitable motion sensor for your lighting application.

4 July 2023
