VOLTAGE DIMMABLE STEP UP DC TO DC LED DRIVERS

In 2021 MEAN WELL expanded their range of step-up DC to DC LED drivers by introducing two new series:

These LED drivers are compact size and potted, which offers some degree of protection against moisture and dust ingress.

Constant current outputs within the LDH series range from 250mA to 1750mA with a power output of up to 60 Watts per module.

The tables below indicate the input and output voltage ranges.

MEAN WELL LDH Series Step-Up LED Drivers

LDH-25 Series (25 Watts* / 9.5~32VDC Input)

Model

Output

Connection Type

LDH-25-250

250mA / 12.5~84VDC

PCB Mount

LDH-25-250W

250mA / 12.5~84VDC  Wire Terminations

LDH-25-350

350mA / 12.5~72VDC  PCB Mount

LDH-25-350W

350mA / 12.5~72VDC  Wire Terminations

LDH-25-500

500mA / 12.5~50VDC  PCB Mount

LDH-25-500W

500mA / 12.5~50VDC  Wire Terminations

LDH-25-700

700mA / 12.5~36VDC  PCB Mount

LDH-25-700W

700mA / 12.5~36VDC  Wire Terminations



LDH-65 (65 Watts* / 9.5~32VDC)

Model

Output

Connection Type

LDH-65-700

700mA / 12.5~80VDC  PCB Mount

LDH-65-700W

700mA / 12.5~80VDC  Wire Terminations

LDH-65-1050

1050mA / 12.5~60VDC  PCB Mount

LDH-65-1050W

1050mA / 12.5~60VDC  Wire Terminations

LDH-65-1400

1400mA / 12.5~46VDC   PCB Mount

LDH-65-1400W

1400mA / 12.5~46VDC  Wire Terminations

LDH-65-1750

1750mA / 12.5~37VDC  PCB Mount

LDH-65-1750W

1750mA / 12.5~37VDC  Wire Terminations

*Power output may vary depending on the model selected. Please check data sheet for actual power output.

MEAN WELL LDH-25
PCB Mount



MEAN WELL LDH-25W
Wire Terminations



The most interesting feature of these DC to DC LED drivers is that they are voltage dimmable. This makes them compatible with a wide range of dimming controllers and switches, including the Power Source D1-10 1-10V dimmer.

PowerSourceD1-10
D1-10 1-10V Dimmer



The LDH-25 gives you a lower cost option for applications where you don’t need so much power.

The LDH-65 is a bit larger, packing more power into the same sized package.

Both series are available in a PCB mount version, or with termination wires for inline installation.

These DC to DC LED drivers are perfect for powering constant current LEDs from a battery, or operating small constant current LED luminaires from a common DC voltage source.

Such applications include cars, trucks, trailers, caravans, boats, camping lights, deck lights, and garden lights.

They are also useful for applications where you need a constant current LED driver at the end of a long run of DC cable, and for constant current street lighting.
